Deep Underwater Borehole Inspection Camera

Available lengths of 300m, 400m & 500m

This is a Deep Underwater Borehole Inspection Camera system now available from Dart Systems Ltd.

Consisting of a dual view waterproof camera with a built-in compass and temperature sensor this unit is used for deep well/ borehole inspection.

The dual view camera head gives a down and side view and can manually rotate 360° and has a Field of View of 120°.

A long high tensile cable is deployed by an electric winch and comes with a control box with a multi-function control panel and has a 128GB HDD. The control box also has audio recording capability.

Available cable lengths are 300m, 400m & 500m.

The winch winding speed can be adjusted from 0 to 20m per minute.

Lighting is supplied by 6 LED's for the down view camera and 6 LED's for the side view camera.

The system also has a built-in WiFi Transmitter supporting Android, iOS smartphone & Tablet over a distance of 30m

Key Features:

  • Dual Waterproof Camera 63mm dia x 610mm length
  • Waterproof to IP68; up to 50 bar
  • High tensile cable with electrical winch
  • Adjustable winding speed (0-20m per minute)
  • 10" LCD Monitor HD DVR
  • Horizontal Resolution 700 TVL
  • Multi-Function control panel (audio/video recording function)
  • Built-in compass & temperature sensor
  • 128GB HDD
  • On Screen Display Depth encoder
  • Winch operating knob (adjust speed, cable up & down, brake)
  • Camera rotation control button (Clockwise & Counterclockwise)
  • Built-in WiFi transmitter up to 30m
  • Power Supply 24v Rechargeable Battery

Packing Dimensions: Package 1 - 92cm x 82cm x 77cm; Weight 227Kgs

                                     Package 2 - 52cm x 32cm x 45cm; Weight 15Kgs

Lead Time: Currently 40-45 days
